Fais Meter luam tawm Circuit Board
1. Qhia meej
Kev Qhia:
Txheej: 2
Board Thickness: 1.65 hli
Kev kho qhov chaw: LF HASL.
Khoom siv: FR4.
Min kab dav / kab nrug: 10 / 10mil
Tooj liab: 70μM
Cov tswv yim rau kev tsim hluav taws xob ntawm cov qauv hluav taws xob hauv theem hauv lub tshuab hluav taws xob (PCB), xws li siv rau hauv lub ntsuas hluav taws xob, tau piav qhia rau hauv no.Uniwell yog ib qho zoo tshaj plaws kev lag luam thiab cov chaw muag khoom uas muaj ob lub chaw tsim khoom, : Kev tiv thaiv thiab kev txiav txim siab me me, lwm qhov ntim nruab nrab thiab kev cog lus loj tshaj plaws.Lawm ntawm peb tus kheej-tshiab innovation thiab kev tshawb fawb, peb lub tuam txhab tsis tsuas yog siv cov tswv yim zoo tshaj plaws hauv ntiaj teb, tiam sis kuj qhia cov cuab yeej zoo tshaj plaws thiab cov cav tov los ntawm Nyiv thiab Asmeskas. Peb cov khoom raug muag thoob plaws ntiaj teb, tshwj xeeb tshaj yog nyob rau hauv Asmeskas, Europe, thiab Middle-East. Nrog rau sab saum toj zoo, txiaj ntsig, thiab cov kev pabcuam zoo, Peb lub tuam txhab muaj lub npe zoo los ntawm cov neeg tuaj txawv teb chaws thiab txawv teb chaws. Peb tab tom yuav yog koj tus khub ntev hauv Suav.
2. PCB Specification
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
3. Peb Lub Hom Phiaj:
(1) Chaw Muag Khoom nyob rau hauv PCB li 10 xyoo.
(2) Ntau tshaj 600 tus neeg ua haujlwm, tshaj li ntawm 300,000 tawm tsib hlis taw ib hlis.
(3) Pom Zoo UL (E314500), IS0 9001, ISO 14001, TS16949
4.FAQ
Q: Peb cov Warranty rau PCBs yog dab tsi?
Peb tau hais kom peb cov laug tho kev tiv thaiv cov khoom siv thiab cov khoom ua haujlwm raws li kev siv sijhawm ntev li 90 hnub ntawm hnub muab khoom xa tuaj ("Warranty Period"). Yog hais tias muaj ib qho teeb meem tshwm sim thiab muaj ntaub ntawv raug cai tau txais nyob hauv lub sijhawm lav warranty, peb mam li hloov lub rooj sib tw khoom pub dawb, ntawm peb qhov kev xaiv, rau cov laug thav ntawv uas tau xa rov qab thiab peb paub tseeb tias peb tsis yog ua raws li cov lus qhia thiab / lossis cov qauv kev lees paub zoo thiab txais kev pom zoo.
Q: Koj puas muaj nqi tshaj rau peb?
Yog, peb yog cov chaw tsim khoom, yog li peb tuaj yeem muab cov nqi tsawg tshaj li lub tuam txhab lag luam.
Q: Peb xav tuaj xyuas koj lub tuam txhab?
Tsis muaj teeb meem, peb yog cov chaw lag luam thiab kev lag luam, tos ntsoov rau koj tuaj txog thiab peb yuav coj koj mus xyuas peb lub Hoobkas thiab ua Hoobkas.
Q: Qhov them nyiaj yog dab tsi?
Rau cov qhua tuaj noj mov tshiab, nws yog 100% prepayment, rau cov neeg laus qub, peb yuav tau txais ib co kev them nqi thiab ib txhia ua ntej xa khoom (Yuav muaj ib txoj kev pib sib koom tes.)
