Txhuas OSP PCB
1. Xa lus piav qhia
Txhuas OSP PCB
General specification rau Aluminium PCB
Txheej suav: 1-2 txheej
Board thickness: 0.5-3.0mm
Tooj dub: 1-3oz
Thermal conductivity: 1.0-4.0W / mK
cov tshuaj tua kab mob: HAL (Lead dawb), Kub kub / Tin, OSP, Kub plating
Daim Ntawv Thov: High Street LED
Nta
1) Cov thermal conductivity zoo
2) Lub cev zoo dua qub
3) SMT
4) Txo kev kub hauj lwm ntawm qhov khoom, muab lub neej ua haujlwm ntawm qhov khoom pov thawj.
2. PCB technical capacity
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
3. Qhia cov ntaub ntawv
MCPCB, Aluminium PCB, los yog hu LED PCB yog cov khoom ntsa hlau uas siv cov khoom siv hlau raws li cov cua kub tshuab luam ntawv, Aluminium PCB muaj cov thermal conductivity, hluav taws xob rwb thaiv tsev thiab cov khoom siv hluav taws xob, nws yog qhov zoo tshaj plaws thiab pheej yig txias kev daws teeb meem.
Uniwell circuits tau ua haujlwm nrog Metal PCB / LED PCB tau ntau xyoo. Peb tau paub ntau txog kev paub thiab kev tsim kev lag luam Aluminium PCB los ntawm ib leeg-ib tog mus rau ob tog uas siv los ua cov teeb pom kev zoo hauv LED. Peb muab qee feem ntau ntawm cov ntawv xov xwm tshaj tawm hauv kev lag luam thiab cov qauv zoo tshaj plaws hauv kev lag luam. Koj tuaj yeem suav rau peb kom ua tau raws li koj xav tau, los ntawm cov kab laug siab yooj yim tshaj plaws rau cov qauv tsim kom tsawg thiab ntau teev loj.
4. Thaj chaw
Teeb pom kev zoo: muaj hwj chim loj, LED teeb rooj, LED taws teeb
Automotive: tsheb teeb, lub teeb pom kev zoo
5. Ntim & xa khoom
Ntim
Txhua yam khoom nrog ESD lub hnab los yog ua rau koj qhov kev thov.
Peb muab ib txheej thawv ntim rau sab nraud, kom paub meej tias tsis muaj teeb meem thaum thauj.
Peb tuaj yeem tau txais tus nqi zoo tshaj los ntawm kev lag luam kev xaib nrog kev ua haujlwm ntev
