Green Solder Mask Aluminium Base LED Circuit Board

Lub npe ntu:

Green solder mask aluminium puag coj circuit board

Khoom siv hauv paus:

Aluminium puag laminate

Txheej suav:

1 txheej

Copper thickness:

1oz 35 ua

Ua tiav board thickness:

1.6mm ib

Solder mask xim:

ntsuab / Dawb / daj / dub / xiav, thiab lwm yam.

Lus dab neeg xim:

Dub / Dawb / Daj

Nto tiav:

Immersion kub

Profile:

CNC + V-CUT

Thermal conductivity:

2.0W/m-K

Insulated txheej yog tawg voltage

Ntau tshaj lossis sib npaug rau 6KV

Qhov chaw thov:

tub yees LED teeb

Halogen Dawb, Rogers, PTFE

Max. Finishing Board Loj

1500 X 610 mm

Min. Board Thickness

0.20 hli

Max. Board Thickness

8. 0 mm

faus / dig muag ntawm (Tsis yog hla)

0.1 hli

Aspect ration

16:01

Min. Drilling Size (Mechanical)

0.20 hli

Tolerance PTH / Nias lub qhov / NPTH

+/-0.0762mm / +/-0.05mm / +/-0.05mm

Max. Txheej suav

40

Max. tooj liab (sab hauv / sab nraud)

6 OZ / 10 OZ

Laum kam rau ua

+/-2mil

Txheej rau txheej sau npe

+/-3mil

Min. kab dav / qhov chaw

2.5 / 2.5 hli

BGA suab

8mil ua

Kev kho saum npoo

HASL, Lead free HASL,

ENIG, Immersion silver/Tin, OSP
