Nreeb taws ua kom muaj hluav taws xob
1. Muab khoom piav qhia
Specification
txheej: 2
Thickness: 0.12 hli
Khoom siv: 1 / 3oz tsis muaj electrolysis gel
Tooj dub: 1 / / 2 oz
Kev kho qhov chaw ntu: kub sinking
Yam tsawg kab dav / kab sib txuas: 0.096mm / 0.1mm
PI reinforcing thickness: 0.1 hli
Lwm yam: cov ntawv hlau yuav tsum muab coj los txhim kho cov PI
Uniwell ua txhua yam los ntawm cov ntawv cog lus rau ib lub vojvoog rau ib lub rooj sib luag rau ntau tus PCBs, Txhua tus PCB peb tsim los ntawm peb qhov kev ntsuam xyuas ceevfaj kom paub meej tias kev ua haujlwm. Peb qhov kev lag luam hauv ntiaj teb no zoo tshaj plaws yuav tsum ua kom muaj tseeb, ua kom-nplua-nplua, flex, thiab tsis yeem luam tawm Circuit Board boards rau txhua tus lag luam yuav tsum tau-los ntawm theem pib kom sib luag thiab txhua yam hauv nruab nrab.
2.Qhov zoo
Yooj yim peev xim: ib zaug & ob txheej, tshaj plaws hauv 3 hnub; ob txheej nplaum flex & nruj, ceev tshaj plaws hauv 4 hnub
Prototypes, muaj peev xwm tsawg zog: 100 hom rau ib lub hlis
Cov cuab yeej muaj peev xwm thiab khoom siv: Cov nplaum hluav taws xob thiab npliag (20L-10F), HDI flex & nruj (1 + N + 1)
3. Ua ntej rau kev sib tw thiab ceev nrawm
Peb muaj peev xwm muab kev pab cuam sai: ib zaug & ob txheej, tshaj plaws hauv 3 hnub; ob txheej flex & txhav, ceev tshaj plaws hauv 4 hnub.
Cov khoom | Flex & Rigid board | Flex lub rooj tsavxwm | |||
Tus qauv qub | Multilayer qauv | Tshwj xeeb qauv | HDI qauv | Tus qauv qub | |
Leadtime (hnub) | 6 | 8 | 10 | 12 | 3-6 |
4.Peb muaj peev xwm ua tau nrog FPC thiab Rigid PCB
Uniwell muaj ntau yam kev txawj ntse nyob rau txhua qhov chaw ntawm kev siv, kev yoojyim, thiab yeem luam tawm Circuit Board board. Los ntawm peb lub sij hawm ceev ceev rau peb qhov kev xaiv loj ntawm cov ntaub ntawv pov thawj rau peb cov kev ua haujlwm uas tsis muaj qhov zoo, Uniwell yog lub chaw tsim hluav taws xob luam tawm lub khw tsim cov lag luam loj tshaj plaws hauv kev lag luam los rau lawv cov hauj lwm PCB.
Peb cov flex, tsis yeem, thiab muaj peev xwm luam tawm ntawm lub rooj tsav xwm muaj xws li:
FPC muaj peev xwm ua tau
Cov khaub ncaws: 20 (xws li 12 players
Kab khiav widest / chaw (mil) hauv kev ua si: 3/3, 3.5 / 3.5
Nam piv: 20: 1 (PTH); 1: 1 (qhov muag tsis pom kev)
Min. drilling qhov (lub hli): 6 (mechanical); 4 (laser)
Nrug deb ntawm drilling rau neeg xyuas pib (mil): 6
Kev kam rau kev tswj hwm tus kheej (+/-): 10%
Muaj peev xwm heev PCB
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
5. Qeg cev
Peb tuav tag nrho cov kev lag luam pov thawj, cov ntawv sau npe, thiab kev ua tub rog kev ua haujlwm, yog li koj tuaj yeem paub tseeb tias txhua lub rooj tsav xwm luam tawm peb ua tau raws li lossis tshaj cov cai tswj kev ua yuam cai. Peb lub PCB muaj peev xwm ua tau zoo thiab kev ua tau zoo tshaj plaws tau tsim cov qauv txij li peb pib tsim PCBs 10 xyoo dhau los.
