1. Muab khoom piav qhia
Specification
Txheej Txheem: 10
Board Thickness: 1.8 hli
Kev kho cov qhov hauv npoo: kub kub.
Khoom siv: FR4.
Min kab dav / kab nrug: 4 / 4mil
Min qhov: 0.25mm
Tshwj xeeb tswj: impedance tswj
1) Qhov kawg: Kev kub / HALS / OSP / Cov ntiv tes kub / Cov ntawv nyeem / Cov xim ntsej muag / Lub khwb xiav xiav / Plating kub
2) Daim npog ntsej muag xim: ntsuab / dawb / daj / xiav / liab / dub
3) Txhaj lo ntxhuav: dawb / dub / daj / liab / xiav / ntsuab
4) Siv rau hauv cov chaw ua haujlwm / cov chaw kho mob / cov khoom siv hluav taws xob / kev sib txuas lus / hluav taws xob.
2. Qhia cov ntaub ntawv
Uniwell Circuits Co., Ltd, tau tsim hauv Shenzhen, Tuam Tshoj hauv lub Plaub Hlis, 2007. Uniwell Circuits yog ib lub tuam txhab muaj kev lag luam tshwj xeeb hauv kev tsim, kev tsim, kev tsim thiab muag khoom ntawm cov neeg muaj kev sib tw ob tog sib tshuam thiab cov PCBs (Printed Circuit Board) ntawm ceev tig, tsab ntawv, qhov nruab nrab thiab loj.
3. PST peev xim
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
4.Qhov chaw nyob zoo
Peb tau cog lus rau:
Ua raws li tej kev cai lij choj
Tiv thaiv kom txhob muaj teebmeem kev xwm txheej
Tiv thaiv kom txhob muaj kuab paug thiab txo qis qis
Tsawg kawg ntawm kev noj cov khoom siv
Kev kawm peb cov neeg ua haujlwm nyob rau hauv kev paub txog kev tiv thaiv ib puag ncig
Teem ib puag ncig Kev Tswj Xyuas thiab txhawb txoj cai ntawm ib puag ncig
RoHS ua raws cai thiab Lead Free
5.Our cov neeg tseem ceeb
Nrog Uniwell Circuits tau txais txiaj ntsim zoo los ntawm cov neeg tuaj ntawm ib ncig lub ntiaj teb, suav nrog Mainland Tuam Tshoj, Taiwan, Tebchaws Asmeskas, Nyiv, Russia, Yelemes, Switzerland, Sweden, UK, Finland, Fabkis, Holland, Ltalis, Poland, Denmark, Australia, Brazil, Singapore, Thaib, thiab Malaysia.
