Muab ob npaug rau sab hauv qab PCB
1. Muab khoom piav qhia
| Muab ob npaug rau sab hauv qab PCB | |
Qhov tseem ceeb ntawm tus qauv: | |
Pawg ntawm tag nrho cov hauj lwm: | 1 KΩ -1 MΩ |
Kev kam rau ua qes: | ± 20% |
Kuj ua kom sov: | 260 ℃ ± 5 ℃, 5sec. ΔTR≤ ± 50% |
Durability: | 1 Zaug Xaiv Tsa Min |
Uniwell Circuits Co., Ltd, yog ib tus zoo manufacturers thiab lwm tus neeg nyob hauv Suav teb, tam sim no theem koj high-tech kua number case pcb los ntawm cov nqi ntawm nws cov Hoobkas kev. Nrog cov khoom siv siab tshaj plaws thiab cov cuab yeej siv high-end tau los ntawm Asmeskas thiab Nyij Pooj, thiab cov neeg ua hauj lwm tsim nyog, peb tuaj yeem paub koj zoo tshaj plaws, muaj lus meej thiab ntev lub neej ntawm peb cov khoom.
2. Kev xyuam xim rau PCB
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
3. Yog xav kom meej meej, nco ntsoov sau cov lus qhia nram qab no rau koj qhov project:
● Ua kom tiav GERBER cov ntaub ntawv nrog rau cov Ntawv Teev Npe tiav
● Lwm hom ntaub ntawv (PCB123, Altium, Eagle, Protel, IVEX, Ultiboard (mus txog V12) thiab OrCAD (nrog .MAX cov ntaub ntawv txuas ntxiv) kuj tau txais raws li kev kaw haujlwm / yeeb yaj duab thiab lwm yam
● "Nyeem Kuv" cov ntawv ceeb toom ntxiv rau cov ntaub ntawv tsim tawm
● Cov Nqi
● Tig lub sijhawm
● Kev Pauv Cov Vaj Huam Sib Luag
● Cov Khoom Uas Yuav Tsum Tau
● Teb kom tiav
Koj cov kev cai tsocai yuav raug xa hauv 2-24 teev xwb, nyob ntawm qhov tsim tsim tsis tau
4.Uniwell chaw tsim tshuaj paus fab
