Xiav lub lauj kaub tais diav tiv thaiv kab hlau lead hauv PCB
1. Muab khoom piav qhia
Kev piav qhia
Cov lus qhia rau xuas tes xiav looj ntsej muag yas txha cob qhia PCB | |
Lub npe: | Xiav lub lauj kaub tais diav tiv thaiv kab hlau lead hauv PCB |
Cov ntaub ntawv hauv paus: | Txhuas laminate laminate |
Txheej suav: | 1 txheej |
Copper thickness: | 1oz los yog 35um |
Tiav lawm daim thickness: | 1.6 hli |
Daim npog qhov ncauj xim: | xiav / liab / ntsuab / dawb / daj / dub / xiav, thiab lwm yam. |
Cov lus dab neeg xim: | Dub / Dawb / Teeb |
Qhov nto tiav: | Kev kub kub |
Profile: | CNC + V-CUT |
Thermal conductivity: | 2.0W / mK |
Insulated txheej tus zom zaws qis | ≥6KV |
Daim ntawv thov: | tub yees LED teeb |
Ntau cov ntsiab lus
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
2. Kev nthuav qhia video
Uniwell circuits co., LTD. yog tsim nyob rau hauv 2007, raws li nyob rau hauv Shenzhen, Tuam Tshoj, tshwj xeeb nyob rau hauv qhuav ntawm luam tawm Circuit Court boards. Raws li keeb kwm Tuam Tshoj raws li PCB chaw tsim khoom, Uniwell manufactures ntau hom PCB, xws li ib tog PCB, ob chav PCB thiab ntau txheej PCB, mus txog 40 txheej. Peb cov khoom miv ntawm MCPCB, CEM-3 PCB, FR-4 PCB yog siv rau cov teeb pom kev zoo, teeb ci, ntsuas, sib txuas lus, siv hluav taws xob, tsheb electronics thiab lwm yam lag luam. Peb muaj kev kub ntxhov ntawm cov kev pab cuam los ntawm PCB prototypes ceev kom ntim loj PCB. Koj tuaj yeem paub ntau ntxiv txog Uniwell los ntawm video txuas, Txais tos tau tuaj xyuas peb lub hoobkas, peb tab tom nrhiav kom tau koj tus khub ntev hauv Suav.
3 .Txhais daim ntawv qhia txog PCB
4.Application
Peb cov poomed pinted Circuit Court board yog dav siv nyob rau hauv lub teeb kev lag luam.
5.Packaging & shipping
Ntim: Ntim cov hnab ntim, Cov hnab yas los tiv thaiv, Cov thawv ntawv zoo.
Kev Tiv Thaiv: Peb yuav xa cov npoo rau koj los ntawm DHL, TNT, UPS, FedEx, Rau cov khoom hnyav, peb yuav xa koj lub PC boards los ntawm lub nkoj los yog cua los txuag nqi thauj. peb kuj tiv tauj lawv rau kev soj ntsuam nrog koj cov khoom xa tuaj.
