Ob tog sided saj zawg zog Board rau laptop inverter
1. Muab khoom piav qhia
Kev Qhia:
Txheej: 2
Thickness: 0.12 hli
Khoom siv: 1 / 3oz glue-free electrolysis.
1/2 oz tooj liab tuab:
Kev kho qhov hauv npoo: ENIG.
Yam tsawg kab dav / kab nrug: 0.1 hli / 0.1 hli.
PI reinforcement thickness: 0.1mm.
lwm yam: yuav tsum tau kos PI kom ntxiv dag zog hauv daim ntawv, hlau ntawv qhov cuab lub zog.
Daim ntawv thov: laptop inverter
2. Txhawb yam muaj peev xwm
FPC Muaj Peev Xwm
Txheej: 20 (suav nrog 12 players)
Kab khiav widest / chaw (mil) hauv kev ua si: 3/3, 3.5 / 3.5
Nam piv: 20: 1 (PTH); 1: 1 (qhov muag tsis pom kev)
Min. drilling qhov (lub hli): 6 (mechanical); 4 (laser)
Nrug deb ntawm drilling rau neeg xyuas pib (mil): 6
Kev kam rau kev tswj hwm tus kheej (+/-): 10%
Yuam kev peev xwm
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
3.Certifications
● UL pom zoo
● ISO9001: 2000 ntawv pov thawj
● Muaj peev txheej 1, 2, thiab 3
4.FAQ
Q: Thaum twg kuv tuaj yeem?
Feem ntau peb hais hauv 24 teev tom qab peb tau txais koj qhov kev nug. Yog tias koj mob heev kom tau tus nqi, thov hu rau peb los yog qhia peb hauv koj tus email kom peb thiaj li yuav suav koj qhov tseem ceeb tshaj plaws
Lus Nug: Kuv tuaj yeem tau txais ib qho qauv los kuaj xyuas koj qhov kev zoo?
Tom qab tus nqi cog lus, koj tuaj yeem yuav tau rau kev kuaj seb puas pom peb zoo.
Yog tias koj xav tau cov kev kuaj, peb tuaj yeem xa tuaj rau koj mus kuaj dawb (nyob ntawm hom qe thiab qty ntawm kuaj) lossis koj tuaj yeem them rau tus nqi qis, thiab nws tuaj yeem them rov qab tau tom qab kev txiav txim siab thaum koj qhov ntau ntawm qhov kev txiav txim loj dua peb cov MOQ.
Q: Koj puas tuaj yeem tsim tus qauv rau peb?
Muaj. Peb muaj ib tug kws ua haujlwm muaj kev nplua nuj kev nyob hauv xaim hlua siv hlua khi & kev sib txig ua ke. Cia li qhia rau peb paub koj cov tswv yim thiab peb yuav pab txhawb nqa koj lub tswv yim rau hauv cov khoom zoo meej. Nws tsis muaj teeb meem yog tias koj tsis muaj leej twg los sau cov ntaub ntawv. Qhia peb cov lus SPEC uas tau ntiag tug. ntawm cov khoom, thiab peb yuav xa koj daim duab tiav rau daim ntawv lees paub.
Q: Ua cas lub sij hawm ua cov hmoov txhuas loj?
Honestly, nws nyob ntawm tus txiav txim kom muaj nuj nqis thiab lub caij koj tso qhov kev txiav txim. Lub sij hawm ua MOQ cov lus qhia yog txog li 10 rau 15 hnub. Feem ntau hais lus, tag nrho cov khoom yuav tuaj yeem ncav cuag koj qhov chaw nyob hauv 4 lub lis piam.
Lus Nug: Koj cov lus cog tseg yog dab tsi?
Peb tau txais EXW, FOB, CIF, thiab lwm yam. Koj tuaj yeem xaiv ib qho uas yooj yim tshaj plaws los sis feem ntau them nqi rau koj.
