Multilayer Flex nruj Circuit Court Board
1. Muab khoom piav qhia
Kev Qhia:
10 pob txha taub hau
Kab dav / qhov chaw: 4 / 6mil
Txawv txawv impedance tswj
Cov PCBs kom yoojyim yog cov cuab yeej ua ke uas muab cov khoom siv sib txig sib luag kom yooj yim thiab siv tau yooj yim
Kev tsim qauv zoo sib xws, thiab muaj peev xwm ua ke nrog ntau hom khoom siv los txhawb ntau yam kev siv rau hauv ib lub xeev ntawm cov flex - feem ntau yog tus nplhaib curved tsim thaum lub sij hawm tsim kev lag luam, los yog tuaj yeem ua rau thaum kawg installation.
Nyob ntawm Uniwell, peb muaj kev zoo siab ntawm peb tus kheej kom xa ib txhia ntawm qhov zoo tshaj plaws nruj tshaj plaws hauv cov ntawv luam tawm Circuit Board boards. Peb xav qhia koj raws nraim peb yuav ua li cas rau koj txoj kev loj hlob, los ntawm engineering thiab prototyping rau loj-ntim txiav txim.
Txuag koj tus kheej lub sijhawm thiab tiv thaiv koj cov peev nyiaj thaum koj hu mus rau Uniwell hnub no los tham txog koj txoj haujlwm yav tom ntej.
2.Cov khoom siv
Cov ntaub ntawv yog qhov tseem ceeb heev thaum nws tuaj mus rau lub rooj sibtham tso rau hauv Circuit Court lossis lub rooj sibfwv hauv cov ntawv luam tawm. PCBs nrog cov ntaub ntawv tsis muaj peev xwm ua rau lub sijhawm tseem ceeb, tawg, ntes hluav taws, ua rau muaj kev phom sij lossis cuam tshuam txog kev lag luam. Uniwell tsuas yog siv cov ntaub ntawv zoo tshaj plaws rau txhua lub PCB kom txaus kom paub tseeb tias koj tau txais cov txiaj ntsim zoo tshaj plaws nrog rau cov teeb liab kis, kev thermal conductivity thiab kev nyab xeeb.
3.Application
Muaj ntau yam zoo nrog kev sib zog ua hauj lwm hauv lub rooj tsav tsheb kom yooj yim siv rau cov khoom siv xws li cov tshuab computer, cov koob yees duab, thiab cov xov tooj hluav taws xob, uas tab tom ua tiav cov miniaturization.
4.FAQ
Q: Qhov chaw me me yog qhov microvia?
Raws li lub ntsiab lus tshiab hauv IPC-T-50M tus microvia yog ib qhov muag tsis pom kev nrog qhov siab tshaj plaws ntawm 1: 1, xaus rau ntawm lub teb chaws uas muaj tag nrho qhov tob tsis tshaj li 0.25mm ntsuas los ntawm tus qauv ntes cov av ntim ntawv lub hom phiaj rau thaj av.
Q: Dab tsi yog meant los ntawm ib tug dig muag ntawm qhov?
Nws yog ib qhov uas khiav ntawm ib txheej sab nraud rau sab hauv txheej, tab sis tsis yog los ntawm tag nrho PCB. Cov hauv dej no tuaj yeem tsim cov tshuab los sis siv cov tshuab laser.Qhov daim duab nyob rau hauv point 1 qhia tau hais tias ib lub lag luam dig muag dig muag ntawm.
Q: Dab tsi yog meant los ntawm ib qho faus ntawm lub qhov?
Qhov no yog ib qhov uas khiav ntawm ib lossis ntau ntau txheej hauv txheej. Lawv yog cov kws kho mob txhua zaus.
Q: Puas muaj ntau hom HDI nta?
Daim duab hauv qab no qhia txog cov qauv tseem ceeb - hom I, hom II thiab hom III raws li tau hais tseg hauv IPC-2226.
Hom I. Kuv txhais ib txheej nkaus xwb microvia rau ib qho los yog ob tog ntawm tus ntxhais. Siv ob qho tib si plated microvia thiab PTH rau interconnection, ntiav cov neeg dig muag, tab sis tsis faus vias.
Hom II. Txhais cov ntsiab lus ntawm microvia rau ib qho los yog ob sab ntawm cov tub ntxhais. Siv ob qho tib si plated microvia thiab PTH rau interconnection. Ua hauj lwm dig muag thiab muab khi ua vias.
Hom III. Tshaj yam tsawg ob lub khaubncaws sab nraud ntawm microvia rau ob leeg lossis ob sab ntawm tus ntxhais. Siv ob qho tib si plated microvia thiab PTH rau interconnection. Ua hauj lwm dig muag thiab muab khi ua vias.
Kev tsim kho lub tswv yim txhawm rau txheeb xyuas cov teeb meem ntawm HDI:
· 1 + n + 1 = ib txheej ntawm microvia (raws li ib hom I thiab hom II saum toj no)
· 2 + n + 2 = 2 khaubncaws sab nraud povtseg ntawm microvia (raws li hom III piv saum toj no)
· 3 + n + 3 = 3 cov khaubncaws sab nraud povtseg ntawm microvia
