Ntse xov tooj Txav tsis yooj yim pcb
1. Muab khoom piav qhia
Parameter:
10 txheej txheej txheej nplaum
Board thickness: 1.5mm
Kab dav / qhov chaw: 3 / 4mil
Lub pas dej: 5mil
Uniwell, kev tsim khoom, ua flex circuits rau koj cov lus qhia meej meej uas muaj kev paub tseeb thiab muaj kev ruaj siab Rigid-flex circuits (A variation of flex circuits) sib txuas nrog cov qauv hluav taws xob nrog ib tus neeg tsav tsheb yau xws li ib lub chaw sib txuas los yog lub rooj sib tham ntawm circuit thiab nrhiav tau hauv daim ntawv thov xws li siv hluav taws xob mus rau cov kev taw qhia txog aircraft.
2. Tsim kab
3. Cov PCB muaj peev xwm rau cov qauv pov thawj
Khoom siv | FR4, CEM-3, Tub Ntxhais Hlau, |
Halogen Dawb, Rogers, PTFE | |
Max. Kev Txiav Txim Siab Hauv Tsev | 1500 X 610 hli |
Min. Board Thickness | 0.20 hli |
Max. Board Thickness | 8.0 hli |
Tshaj / Qhov muag pom ntawm (Tsis yog-tus ntoo khaub lig) | 0.1 hli |
Ntsuas phaj | 16:01 |
Min. Drilling loj (Mechanical) | 0.20 hli |
Txoj kev siab ntev PTH / nias ncov lub qhov / NPTH | +/- 0.0762 mm / +/- 0.05mm / +/- 0.05mm |
Max. Txheej Suav | 40 |
Max. tooj (puab / txheej) | 6OZ / 10 OZ |
Lam ua siab ntev | +/- 2mil |
Txheej rau txheej sau npe | +/- 3mil |
Min. kab dav / qhov chaw | 2.5 / 2.5mil |
BGA suab | 8mil |
Kev kho qhov chaw deg | HASL, Ua dawb HASL, |
ENIG, Txhim nyiaj silver / Tin, OSP |
4. FPC muaj peev xwm
Txheej: 20 (suav nrog 12 players)
Kab khiav widest / chaw (mil) hauv kev ua si: 3/3, 3.5 / 3.5
Nam piv: 20: 1 (PTH); 1: 1 (qhov muag tsis pom kev)
Min.drilling qhov taub (mil): 6 (mechanical); 4 (laser)
Nrug deb ntawm drilling rau neeg xyuas pib (mil): 6
Kev kam rau kev tswj hwm tus kheej (+/-): 10%
5. Kev xav cov lus xav tau muaj xws li:
● Ntsaws cov pob khoom dhos ua kom muaj kev sib txuas hluav taws xob hauv 3 qhov tsom (daim ntawv thov zoo li qub).
● Hluav taws xob sib txuas rau qhov chaw sib koom ua ke yuav tsum tau ua kom yooj yim rau lub sijhawm siv (cov ntawv thov dynamic).
● Caw hnyav rau daim ntaub ntawv xws li cov cuab yeej siv tes, lub dav hlau los yog kev loj thauj mus los ntawm qhov chaw uas lawv hloov qhov nyhav dhau los thiab cov tshuab xaws hlau.
● Hauv qhov chaw txwv tsis pub siv cov khoom siv ntawm cov yas txig lossis cov hlua khuam hauv cov hlua hluav taws xob tuav muaj ntau qhov zoo.
● Cov ntaub ntawv ua kom zoo tshaj qhov uas yuav tsum tau muaj cov khoom siv hluav taws xob los yog cov khoom siv hluav taws xob thaiv.
Ua tus thawjcoj Flex Circuits tus thawjcoj, Uniwell khoom siv thiab hloov cov khoom nyias, cov ntaub ntawv yooj yim thiab kev cai composites los ntawm cov khoom siv thoob ntiajteb. Peb muab ib zaug thiab ntau txheej nplua suab hloov tau yooj yim nyob qhov twg hauv daim ntawv thov yuav tsum tau interconnections hauv lub pob compact. Peb cov qauv hluav taws xob me me thiab sib zog, thiab muaj peev xwm seamlessly integrate mus rau hauv txhua daim ntawv uas koj xav tau.
